MODEL
|
SIZE |
VOLTAGE（V） |
CURRENT（A） |
SPEED（RPM） |
AIR FLOW（CFM） |
PRESSURE（mmH2O) |
NOISE(dBA) |
WEIGHT(g) |
| HXD2510 |
25X25X10 |
5 |
0.32 |
20000 |
4.6 |
19.2 |
38 |
6.5 |
| 0.20 |
13000 |
3.0 |
8.1 |
32 |
| 0.14 |
10000 |
2.4 |
5.6 |
27 |
| 0.10 |
7000 |
1.6 |
2.5 |
23 |
| 12 |
0.20 |
20000 |
4.6 |
19.2 |
38 |
| 0.12 |
13000 |
3.0 |
8.1 |
32 |
| 0.10 |
10000 |
2.4 |
5.6 |
27 |
| 0.08 |
7000 |
1.6 |
2.5 |
23 |
| 24 |
0.10 |
20000 |
4.6 |
19.2 |
38 |
| 0.08 |
13000 |
3.0 |
8.1 |
32 |
| 0.06 |
10000 |
2.4 |
5.6 |
27 |
| 0.05 |
7000 |
1.6 |
2.5 |
23 |
Ball Bearing 70,000hrs (40°C)
Sleeve Bearing 30,000hrs (40°C)
Temperature Range:
Operating temperature -10'C-70°C (Non-condensing)
Storage temperature -40°C-75°C(Non-condensing)
Safety Standards:RoHS, CE,FCC
Bearing type：1.Sleeve bearing(lower price):The sleeve was stalbe performance and easy installation Lifetime: 30,000h
2.Ball bearing(high price):it is charactered with high quality,low noise level and easy installation. Lifetime: 50,000h
Wire：1.Auto-restart function
2.Stopage Alarm function(RD function with 3 lead wires)
3.Speed detection function( FG function with 3 lead wires)
4.Temperature control speed function(PWM function with 4 lead wires)
5. RD, FG, PWM(5 lead wires)
