MODEL
|
SIZE |
VOLTAGE（V） |
CURRENT（A） |
SPEED（RPM） |
AIR FLOW（CFM） |
PRESSURE（mmH2O) |
NOISE(dBA) |
WEIGHT(g) |
| HXD12025 |
120X120X25 |
5 |
0.20 |
1500 |
52.58 |
1.37 |
24.5 |
118 |
| 0.30 |
2000 |
56.05 |
2.01 |
29.0 |
| 0.50 |
2500 |
59.75 |
2.58 |
32.0 |
| 12 |
0.12 |
2000 |
52.58 |
3.69 |
24.0 |
| 0.20 |
3000 |
59.75 |
6.27 |
32.0 |
| 0.30 |
4000 |
93.52 |
13.65 |
32.48 |
| 24 |
0.15 |
2000 |
59.75 |
2.58 |
37.82 |
| 0.30 |
3000 |
87.26 |
6.27 |
40.12 |
| 0.40 |
4000 |
132.59 |
13.65 |
51.0 |
| 48 |
0.10 |
2000 |
59.75 |
2.58 |
32.48 |
| 0.15 |
3000 |
87.26 |
6.27 |
40.12 |
| 0.20 |
4000 |
132.59 |
13.65 |
51.0 |
Expected Life:
Ball Bearing 70,000hrs (40°C)
Sleeve Bearing 30,000hrs (40°C)
Temperature Range:
Operating temperature -10'C-70°C (Non-condensing)
Storage temperature -40°C-75°C(Non-condensing)
Safety Standards:RoHS, CE,FCC
Bearing type：
1.Sleeve bearing(lower price):The sleeve was stalbe performance and easy installation Lifetime: 30,000h
2.Ball bearing(high price):it is charactered with high quality,low noise level and easy installation. Lifetime: 50,000h
Wire：
1.Auto-restart function
2.Stopage Alarm function(RD function with 3 lead wires)
3.Speed detection function( FG function with 3 lead wires)
4.Temperature control speed function(PWM function with 4 lead wires)
5. RD, FG, PWM(5 lead wires)
